proweld arc 1850 Exploded View and Parts Diagram
| Number | Quantity | Item Number | Description | Hanlon Part Number | Buy Now |
|---|---|---|---|---|---|
| 1 | 1 | 104-0014 | Switch | 104-0014 | Buy Now |
| 2 | 1 | 104-0016 | On/Off Operator | 104-0016 | Buy Now |
| 2 | 1 | 104-0017 | N.O. Contact | 104-0017 | Buy Now |
| 2 | 1 | 102-0018 | N.C. Contact | 102-0018 | Buy Now |
| 3 | 1 | 102-0087 | Power Light (Neon Green) | 102-0087 | Buy Now |
| 4 | 1 | 102-0060 | Konb | 102-0060 | Buy Now |
| 4 | 1 | 111-0012 | Potentiometer | 111-0012 | Buy Now |
| 5 | 1 | 108-0028 | Red LED | 108-0028 | Buy Now |
| 6 | 1 | 103-0004 | Panel Meter | 103-0004 | Buy Now |
| 7 | 1 | 108-0029 | Green LED | 108-0029 | Buy Now |
| 8 | 1 | 108-0030 | Amber LED | 108-0030 | Buy Now |
| 9 | 1 | 102-0058 | Positive Output Terminal | 102-0058 | Buy Now |
| 10 | 1 | 107-0001 | R&S 4 Pole Panel Mounted Connector | DISCONTINUED | |
| 10a | 1 | CCPW-PM | NEW STYLE Proweld Cable Connector | CCPW-PM | Buy Now |
| 11 | 1 | 102-0057 | Negative Output Terminal | 102-0057 | Buy Now |
| 12 | 1 | 102-0007 | Fuse 6 Amp 600 Volt | 102-0007 | Buy Now |
| 13 | 1 | 105-0015 | Control Transformer | 105-0015 | Buy Now |
| 14 | 1 | 102-0083 | Fan Blade 14" | CALL FOR PRICING | |
| 15 | 1 | 102-0085 | Fan Motor | CALL FOR PRICING | |
| 16 | 1 | 113-0017 | Start Connector | 113-0017 | Buy Now |
| 17 | 1 | 105-0023 | Main Transformer | 105-0023 | Buy Now |
| 18 | 1 | 102-0107 | Shunt | CALL FOR PRICING | |
| 19 | 1 | 102-0032 | Weld SCR Thermostat | CALL FOR PRICING | |
| 20 | 1 | 102-0109 | Weld SCR Clamp | CALL FOR PRICING | |
| 21 | 1 | 102-0109 | Weld SCR | CALL FOR PRICING | |
| 22 | 1 | 105-0004 | Choke Coil | 105-0004 | Buy Now |
| 23 | 1 | 600-0010 | Time Control PC Board | 600-0010 | Buy Now |
| 24 | 1 | 600-0012 | Current Control PC Board | 600-0012 | Buy Now |
| 25 | 1 | 600-0011 | Monitor Control PC Board | 600-0011 | Buy Now |
| 26 | 1 | 600-0010 | Time Control PC Board | 600-0010 | Buy Now |
| 27 | 1 | 104-0015 | Fuse Block | CALL FOR PRICING | |
| 28 | 1 | 108-0042 | Sustaining Arc SCR | 108-0042 | Buy Now |
| 29 | 1 | 106-0024 | Gun Discharge Capacitor | 106-0024 | Buy Now |
